Factory Lead Time

24 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

2-XDFN

Number of Pins

2

Diode Element Material

SILICON

Operating Temperature (Max)

150°C

Operating Temperature (Min)

-55°C

Number of Elements

1

Packaging

Tape & Reel (TR)

Published

2014

JESD-609 Code

e4

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

2

ECCN Code

EAR99

Terminal Finish

Nickel/Gold (Ni/Au)

Capacitance

35pF

Terminal Position

BOTTOM

Terminal Form

NO LEAD

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Element Configuration

Single

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Diode Type

Schottky

Current - Reverse Leakage @ Vr

75μA @ 40V

Voltage - Forward (Vf) (Max) @ If

460mV @ 500mA

Forward Current

500mA

Operating Temperature - Junction

-55°C~150°C

Output Current-Max

0.5A

Forward Voltage

460mV

Max Reverse Voltage (DC)

40V

Average Rectified Current

500mA

Peak Reverse Current

75μA

Max Repetitive Reverse Voltage (Vrrm)

40V

Capacitance @ Vr, F

35pF @ 4V 1MHz

Max Forward Surge Current (Ifsm)

14A

Reverse Voltage (DC)

40V

RoHS Status

ROHS3 Compliant
